English
6
AdjUSt tHe SAddle AnGle
Adjust your saddle to the angle and fore-aft position of your preference, then use a
4 mm hex to tighten each seat clamp bolt, in an alternating fashion, to 8-10 N·m
(70-89 in-lb).
4
8-10 N·m
(70-89 in-lb)
7 AliGn tHe SeAtPoSt to tHe fRAMe
If necessary, loosen the seat clamp device on your frame and
align your seatpost so that the saddle is in line with the top
tube of your frame. Re-torque the seat clamp device to the
frame manufacturer's specifications or 5-6 N·m (40-60 in-lb),
whichever is lower.
8 inStAll tHe ReMote (diScRete clAMP)
Close the remote clamp around the handlebar. Insert the remote clamp bolt and use
a T25 TORX ®
remote clamp to the desired position and tighten the clamp bolt to
5-6 N·m (43-52 in-lb).
6
to loosely tighten the bolt to hold the assembly together. Rotate the
Reverb User Manual
8-10 N·m
4
(70-89 in-lb)
95-4215-005-000 Rev A
