Grounding the Switch
1. Connect one end of the grounding cable to a proper earth ground, such as the rack in
which the switch is mounted.
2. Secure the grounding lug to the grounding point on the switch with the washers and the
screw.
CAUTION:
connections have been disconnected.
Connecting the RJ45 Ports
1. Connect an Ethernet cable to the RJ45 port of a network device.
2. Connect the other end of the Ethernet cable to the RJ45 port of the switch.
The earth connection must not be removed unless all supply
H z
5 0 / 6 0
0 V A C
1 0 0 - 2 4
