ASSEMBLY
EN
WARNING:
If any parts are damaged or missing,
do not operate this product until the parts are replaced.
Use of this product with damaged or missing parts could
result in serious personal injury.
WARNING:
Do not attempt to modify this product
or create accessories not recommended for use with this
brush cutter. Any such alteration or modification is misuse
and could result in a hazardous condition leading to
possibly serious personal injury.
WARNING:
To prevent accidental starting that could
cause serious personal injury, always remove the battery
pack from the machine when assembling parts.
WARNING:
When the machine is equipped with
brush cutter head, the safety barrier bar shall be mounted.
MOUNTING THE GUARD
WARNING:
Always wear gloves when mounting or
replacing the guard. Take care of the blade on the guard
and protect your hand from cutting.
WARNING:
Never operate the machine without the
guard firmly in place. The guard must always be on the
machine to protect the user! When the guard is fixed, never
attempt to remove or adjust the guard, if a replacement
is needed, it should be performed by a qualified service
technician!
Loosen and remove the two screws from the guard (Fig. C),
align the guard mounting holes with the assembly holes
and then lock the guard onto the shaft base with the two
screws, together with two spring washers (Fig. D).
Make sure the guard is fixed according to Fig. C & D, any
reverse fixing will cause great danger!
MOUNTING THE BLADE
1. The blade is shipped with a sheath. Before mounting
the blade onto the brush cutter, the sheath should be
removed by undoing the clamp wire from the hook on
the sheath (Fig. E).
Fig. E parts description see below:
E-1
Hook
E-2
Clamp Wire
2. Rotate the outer flange to align the slot in the inner
flange with the shaft-locking hole in the gear case
(Fig. F).
10
BRUSH CUTTER ATTACHMENT — BCA1200
3. Insert the hex wrench provided into the aligned holes
to act as a stabilizer (Fig. G).
Fig. F & G parts description see below:
F-1 Gear Case
F-2 Aligned Shaft-locking
Holes
4. Position the brush cutter head against a solid surface
for support. With one hand grasping the brush cutter
shaft and use the other hand to grasp the multi-
function wrench provided to loosen the nut in the
direction of the arrow marked on the outer flange and
remove the nut and the outer flange. Save them for
reassembly (Fig. H).
5. Mount the blade onto the motor shaft, ensuring that
the surface of the blade is flush with the surface of
the inner flange bulge. Go on mounting the outer
flange and the nut (Fig. I). Pre-tighten the nut in
COUNTERCLOCKWISE by hand.
Fig. I parts description see below:
I-1 Inner Flange Bulge I-4 Outer Flange
I-2 Motor Shaft
I-3 Nut
6. Rotate the outer flange to align the slot in the inner
flange with the shaft-locking hole in the gear case
and insert the hex wrench provided into the aligned
holes to act as a stabilizer as previous step 2 & 3
shown.
7. Position the brush cutter head against a solid surface
for support. With one hand grasping the blade and
use the other hand to grasp the multi-function
wrench provided to tighten the nut opposite the
direction of the arrow marked on the outer flange
(Fig. J).
Use of Guard Accessory
NOTICE:
When the tool is used as a line trimmer
equipped with a trimmer head, the guard accessory must
be mounted onto the guard (Fig. K).
Secure the guard accessory onto the guard by tightening
the three screws with the hex wrench provided. Failure
to comply could result in an overly long cutting line and
motor overload.
CONNECTING THE BRUSH CUTTER ATTACHMENT TO
THE POWER HEAD
This brush cutter attachment is designed for use with EGO
Power Head PH1400E/PH1420E/PHX1600.
See "INSTALLING AN ATTACHMENT TO THE POWER
HEAD" section in the power head PH1400E/PH1420E/
PHX1600 operator's manual.
