WE2111, Command Descriptions
2 Basic command set
A3953-1.0 en/de
The Basic level allows for simple weight acquisition by
PLC or computer from a number of WE2111 on a simple
RS232 or RS422 network. The extended network
language allows for full control over all functions of the
instrument. The section here describes only the basic
command structure. For the Extended structure refer to
chapter 16.
The WE2111 may be set to respond to commands sent
via the serial port from a PLC or PC. The command
structure is:
STX K Command Poll ETX
where:
STX (1 byte): 02
K (1 byte): 4B
H
Command (1 byte): 1 character command (defined
below)
Poll (2 bytes): the network address (set in SERIAL ->
NET.OPT -> ADDRESS). 00 is the broadcast address
ETX (1 byte): 03
Command Description
z Zero key press
Z Zero key long press
T, t Tare key press
G, g Gross/net key press
P, q Print key press
Q Print key long press
H
H
5
