Dustcontrol S34000 EX Montageanleitung Seite 32

Technical Data
According to design, the maximum ATEX zones for the filter units are as follows:
• The dirty side of the filter is sufficient up to Zone 21
• The clean side of the filter is sufficient up to Zone 22
• The area around the unit is sufficient up to Zone 22. Observe the safety instructions from the supplier regarding
the explosion panel.
Technical data
H x B x D [mm]
Weight [kg]
Inner diameter [mm]
Inlet [mm] *
Outlet [mm]
Maximum recommended air flow [m
Filter
2
Filter area, antistatic [m ]
Filter classification
Filtration efficiency [%]
Container [l]
Max. temperature filter [° C]
ATEX
Vent [mm]
Explosion pressure relief [Optional]
P [bar]
red
Filter cleaning with reverse air pulse
Compressed air [bar]
Connection, hose [mm]
Volume, dirty side [l]
Art. no.
Dimensioning of blast hatch is done together with the customer based on current needs. For dimensioning of the
blast hatch is required; material type, Kst and P
* Note that the dirt volume in the filter changes depending on the size of the inlet.
S34000 EX
S34000 EX
3250 x 1250 x 1325
330
Ø 1046
Ø Optional
Ø 250
3
/h] 4000
34
EN 60335-2-69, Klass M
99,9
60
130
Ø393 mm FIKE 400
Ø415 EVN 3.0 420
Ø475 EVN 3.0 480
Blasting plate, explosion valve, Q-Rohr®
0,5
4
8
1117
105901 FIKE 400
105902 EVN 3.0 420
105903 EV 3.0 480
.
max
32
