2.7 Electrical connection
Attention
The general and local regulations must be observed. Therefore, this step may only be carried
out by a trained specialist.
Pay attention to the necessary supply line.
The connection should be made according to the product with a 230V Schuko plug (230V version), or with a
CEE plug, 5-pin, 400V/16A (400V version).
Voltage deviations should not exceed 0.9 - 1.1 times the nominal voltage range and frequency deviations should
not exceed 0.99 - 1.01 times the frequency range. To be able to guarantee this, necessary protective measures
must be taken.
At the end of the work, the direction of rotation of the motor must be checked.
2.8 Hydraulic connection
Before the system is put into operation or operated with oil for the first time, the following must be
observed with regard to optimum, trouble-free and virtually air-free operation:
All hydraulic lines must be connected and tightened in accordance with the hydraulic diagram and, if
applicable, the hose designation.
All hydraulic lines and cylinders must be vented according to the hydraulic plan or hose designation.
In order to ensure the proper and safe functioning of the system and the hose lines used, it is essential to
ensure that the hydraulic fluids used comply with the specific specifications and recommendations of the
manufacturer.
Media used that do not meet the specific requirements or are contaminated will damage the entire hydraulic
system, shorten the service life of the hydraulic systems used and lead to the exclusion of liability and
warranty.
Note
It is also possible to contaminate the system by refilling it with oil
The minimum requirement and minimum oil quantity must be checked or produced.
2.9 Assembly
Note
These instructions are not to be regarded as assembly instructions; they only provide
information and assistance for competent and skilled fitters.
