ECOVACS WINBOT W710 Kurzanleitung Seite 2

Quick User Guide
Important notes to help you get a quick start
WINBOT is NOT intended to replace heavy duty or first time cleaning, this must be done manually as you have done in the past. WINBOT is intended for maintenance
cleaning on standard windows.
Warning
EN
If WINBOT is used to clean a window above ground level, the Safety Pod MUST be used.
WINBOT must be used in strict accordance with the directions in the Instruction Manual. ECOVACS can not be held liable or responsible
for any damages or injuries caused due to improper use.
1. Make sure that there is enough power cord for the WINBOT to clean the entire window without restricting its movement. If there is not enough cord, it is not safe to use the
WINBOT on that particular window until a WINBOT Extension Cord is attached.
2. Loop one end of the Safety Rope around the Safety Pod's channel and pull it tight.
3. Loop the other end of the Safety Rope to the power connector on the power cord and tighten.
4. If an Extension Cord is attached, the Safety Rope must be tied to the power connector on the Extension Cord.
Note: Do NOT attach the Safety Rope to the thin part of the cord.
5. Press the Safety Pod suction cup FIRMLY in the lower corner on the opposite side of the glass you are cleaning. Make sure the Safety Pod suction cup is securely in place.
6. Place WINBOT on the window, close the window if cleaning the outside of the window, and start WINBOT.
7. After WINBOT is done cleaning remove it from the window. Grasp the handle, switch the unit OFF, insert finger into Air Release Trigger and pull up on it for 20 seconds until
suction has diminished.
1. IMPORTANT SAFETY INSTRUCTIONS
1. Should you be cleaning the outside of the window, you must use the Safety Pod. Read the instructions on Safety Rope use in your Instruction Manual.
2. When removing the WINBOT, grasp the handle of the unit and move the switch under the handle to the left - OFF position, and while still grasping the unit,
insert finger into the Air Release trigger and Pulling up on it, remove the unit from the window when the suction has diminished.
3. Place the WINBOT horizontally on the window and about 10cm
4. The unit may NOT be used outside while raining, snowing or colder than 5
2. PREPARATION BEFORE USE
●
While the unit is charging, take time to read the Instruction Manual for Safety Notes and proper use of the unit.
●
For most of your windows, the cord supplied will meet your demands. Should you be cleaning the outside of the window, you must use the Safety
Pod. Read the instructions on Safety Pod use in your Instruction Manual.
3. USE OF PRODUCT
●
Grasping the unit by the handle, place the unit on the window which is most convenient to you, BUT making sure it is at least 10cm (4
the corner of the window frame.
●
While still having a hold on the handle, move the switch from the OFF position (far left) to the ON position (Center) and you will hear a slight noise.
This is the vacuum motor creating suction to hold the unit to the window. When the indicator light turns BLUE, the unit has attached itself to the
window and you can now let go of the handle.
●
After ensuring the WINBOT is correctly placed on the glass, press "
on the Main Unit, then the product will use automatic cleaning mode for cleaning the window and when finished cleaning will return to the start
position.
●
If you want the product to pause during the cleaning, press "
Main Unit, then the product will pause working and go on standby.
●
When the unit is done cleaning and has returned to the START position, grasp the handle of the unit and move the switch under the handle to the OFF
position - left, and while still grasping the unit, insert finger into the Air Release trigger and Pulling up on it, remove the unit from the window.
For more complete and detailed information, please refer to Instruction Manual, which provides important safety, use and maintenance information.
Do NOT replace reading the Instruction Manual with review of the Quick User Guide.
(4'') from the lower corners of the window.
●
Before charging, please firstly turn on the
the WINBOT. (" " OFF " " ON. The default state is " ") Otherwise,
WINBOT can NOT be charged or working.
●
Plug the adapter into your electrical receptacle and assemble the two
connectors, tightening the nut so the connector will not pull apart. Place
the WINBOT's switch button, located under the handle, in the Charging
Position " " (far to the right) and charge for 2 hours. The indicator
light flashes GREEN and will go to a steady GREEN when the charging is
complete.
●
You MUST place the large cleaning pad on the front floating plate, making
sure to cover the whole plate. The smaller cleaning pad to be attached to
the rear of the unit in the space provided.
●
Make sure the button on the bottom of the WINBOT is turned ON.
●
Just prior to placing the unit onto the window, take the glass cleaning
solution bottle and spray ONLY the FRONT pad. The pad should just be
damp.
" button on the Remote Control momentarily or directly press "
℃ (40℉)
as it will damage the product and could cause electrical problems.
button at the bottom of
" button of the Remote Control momentarily or directly press the "
OFF ON
''
) up and in from
" button
" button on the
