4. Technical data
Cutter rail length .
Cutting length
Tooth spacing .
Cuts/min
Charging time
Soundpressure level, L PA
Sound power level,
K / KWA uncertainty..
Interchangeable battery ......18 V d.c./ 2000 mAh
. (optional 18 V d.c./ 1500 mAh)
(optional 18 V d.c./ 3000 mAh)
(optional 18 V d.c./ 4000 mAh)
— (optional 18 V d.c. / 5200 mAh)
Vibration an
K uncertainty.
Weight .
Battery charger
Mains voltage . ......200-250
Output voltage/current
The machine may exceed 85 dB (A). The operator
will require noise protection measures if this is
the case. The noise was measured
with EN 60745-1. The value of the vibrations
ted by the handle was determined in accordance
with EN 60745-1.
The specified vibration value was established in
accordance with a standardized testing method. It
may change according to how the electric equip-
ment is used and may exceed the specified value
in exceptional circumstances.
The specified vibration value can be used to
compare the equipment with other electric power
tools.
The specified vibration value can be used for initi-
al assessment of a harmful effect.
Keep the noise emissions and vibrations
minimum.
Only use appliances which are in perfect wor-
king order.
Service and clean the appliance regularly.
Adapt your working style to suit the appliance.
Do not overload the appliance.
Have the appliance serviced whenever ne-
cessary.
18
Switch the appliance off when it is not in use.
•
Wear protective gloves.
620 mm
550 mm
5. Before starting the equipment
18 mm
2200
Fitting the hand guard
ca. 40 min.
Attach the hand guard (Fig. I/ltem 2) in the di-
64.8 dB (A)
rection of the arrow as shown in figure 4a. Next,
84.8 dB (A)
fasten this with the 2 screws (Fig. I/ltem 10) as
shown in Fig. 4b.
Assembly
Attach the steady grip (Fig. 2/1tem 3) in the direc-
tion of the arrow as shown in Fig. 4c.
Important: The lock (Fig. 4c/ltem I I) must be on
the right-hand side! Make sure that the electrical
1,494 m/s2
contacts are connected correctly.
. 1.5 m/s2
Then fully tighten the screw (Fig. 4d/ltem 12) with
.....2.4 kg
the lock closed (Fig. 4c/ltem 11).
Adjustable
V - 50-60 Hz
The steady grip is adjustable. Loosen the lock
.....21 Vd. c./3A
(Fig. 4c/ltem 1 1) by opening, bring the steady grip
into the desired position and attach it again by
closing the lock (Fig. 4c/Item I I).
in accordance Swivel
emit- The hedge trimmer is fitted with a rear swiveling
handle. It can be swiveled 900 to the left and right.
To do so, pull the slide (Fig. 13/1tem 10) in the di-
rection indicated by the arrow and turn the handle.
To return the handle to its original position you
must pull the slide (Fig. 13/1tem 13) in the direc-
tion indicated by the arrow again. The handle
should be turned through 900 for vertical cuts.
Fitting the cuttings
For horizontal cutting we recommend that you
install the cuttings collector. This enables you
to remove the cuttings easily. The surface of the
hedge thus remains clear (Fig. 5a/5b). Position
the cuttings collector (14) on the cutter rail (Fig.
5c). Then push the cuttings collector as far as
possible towards the tip of the cutter rail and
to a secure it with the fastening screws (15) (Fig. 5d).
The cuttings collector can be fitted on either the
right or left side.
Installing
Press the side pushlock buttons of the battery
pack as shown in Fig. 4e and push the battery
pack into the mount provided. When the battery
pack is positioned as in Fig. I, make sure that the
-18-
of the steady grip
steady grip
handle
collector (Fig. 5a-5d)
the battery (Fig. 4e)
