3 THE VISOR
Reference images on page 132.
The scratch-resistant AX9 helmet polycarbonate visor has a mechanism that allows
a rotation movement.
The visor is attached to the shell through holes at both ends.
The fastening elements and their positions also ensure its movement. The shaped tooth
on the inside of the visor interacts with the grooves of the moving mechanism, to ensure
stability in the different opening positions (img. 01).
The moving mechanism allows for 5 positions of use:
›
1 visor closed, recommended when travelling at high speed.
›
1 micro opening, creating a small space between the visor and the visor edge, to ensure a
moderate air flow when travelling at slow speed.
›
2 intermediate positions, for partial opening of the visor.
›
1 fully open and fully up position. This position is only appropriate whilst putting the
helmet on, with the vehicle stopped.
We recommend that all removal and reassembly activities are completed with the
helmet on a flat support base.
3.1 REMOVAL
Fully close the visor. Using a screwdriver or a coin, start working on one of the fastening
mechanisms on the sides of the helmet.
Loosen and remove the screw, together with the plastic anti-rotation plate (img. 02), detaching
the visor from the shell.
Repeat on the other side and remove the visor.
3.2 INSTALLATION
Start on the fastening mechanism on one side of the helmet.
Using a screwdriver or a coin, join the components together (img. 02) and tighten the screw to a
torque of 1,5 Nm.
Repeat on the other side and then try to open and close the visor to ensure that its movement is
correct.
