4 THE PINLOCK
INSERT
Reference images on page 134.
The Pinlock anti-fog insert is supplied with the AX9 helmet and must be fitted on the
®
inside of the visor. Made of moist absorbing plastic material, this inserts reduces the
formation of fogging. It has been designed to perfectly adapt to the shape of the visor,
creating an insulating and hermetically sealed air chamber that does not compromise
the field of vision.
Anti-fog devices delay the formation of condensation, but do not prevent it from
occurring. This means that with anti-fog inserts, it simply takes longer for
condensation to form. Mist can and will form on the visor under certain environmental
conditions. We recommend that Pinlock
below 20° C and humidity levels exceeding 70%. We recommend that Pinlock
are always used when it's raining.
To install the Pinlock
helmet.
4.1 INSTALLATION
Position the Pinlock insert on the internal surface of the visor, making sure that the silicon seal
®
is in contact with the visor itself.
Secure the left side of the Pinlock
the inside of the visor in the shaped hollow found on the left side of the insert (img. 03).
Slightly bend the Pinlock
®
Secure right side of the Pinlock
inside of the visor in the shaped hollow found on the right side of the insert (img. 05).
Make sure that the silicon seal on the edge of the Pinlock
along the whole perimeter (img. 05).
Remove the protective film on the Pinlock
in the previous chapter.
inserts are always used with air temperatures
®
insert, we recommend that you first remove the visor from the
®
insert to the visor by placing the ratchet found on the left on
®
insert (img. 04) and help it adhere to the visor.
insert to the visor by placing the ratchet found on the right on the
®
insert and refit the visor on the helmet as indicated
®
ANTI-FOG
®
insert adheres perfectly to the visor
®
