Watts Vision WFC-03 6Z HC 24 Kurzanleitung Seite 2

!
TRF02 230/24 (Option)
PPLIMW15610Ac-QIG-FR-W-FR-01-24-Rev1
1
Off
OUT OUT OUT OUT
230 V~
JUNCTION
CONNECTOR
Cool Heat
live live
1 LED/zone
a
230V
OUT
SECU IN
IN
IN
Z1/Z2
Z=Z1+Z2
0 V~
230 V~
IN
(1)
0 V~
230 V~
Maximal humidity percentage
Electrical protection
IP protection
Shipping and storage temperature
Operating temperature
Power supply
Output maximum load (5 outputs)
Actuators
Compatibility
Quick Installation Guide
2
NC Actuator OUT
Z3/Z4 Z5/Z6 Z7/Z8
Z=Z3+Z4 Z=Z5+Z6 Z=Z7+Z8
L Lout N
L Lout N L Lout N
WT-A03 WT-A03 HC
85% at 20°C (68°F)
Class II with junction connector
continuity of earth
IP30
-10°C to 50°C (14°F to 122°F)
0°C to 50°C (32°F to 122°F)
230 Vac ± 10% 50Hz
24Vac ± 10% 50Hz (with transfo)
Relay: 5A (1A)
5A external fuse must be installed to protect
all relay outputs (embedded fuse protects only
actuator outputs and electronics of the device)
230V /24V NC up to 3W
WT-A03 / WT-A03 HC / WT-D03 / WT-DP03
B.P. N°10 - Z.A. des Tourettes • 43800 ROSIERES • France
Tél. +33 (0)4 71 57 40 49 • Fax. +33 (0)4 71 57 40 90
Sales-rosieres@wattswater.com • www.wattswater.fr
b
L Lout N
WT-D03
to ensure
(1)
Watts Electronics S.A.S.
© 2023 Watts
