Package contents
• AXIS Q6052-E/Q6054-E Mk II/Q6055-E PTZ Dome Network Camera
• Clear dome cover (premounted)
• Sunshield, including screws T20 (3x)
• RJ45 Push-pull Connector (IP66)
• Axis High PoE midspan 1-port (LPS)
• Printed materials
- Installation Guide (this document)
- Extra serial number label (2x)
- AVHS Authentication key
Hardware overview
NO NO TICE NO TICE TICE
Make sure the dome is attached in operation mode, otherwise focus may be affected.
1
Hook for safety wire
2
Network connector (High PoE)
AXIS Q60-E Series
7
