Bolt-down instructions
(For select models only)
WARNING: Product is not water resistant once it is bolted down.
The ETL verified water resistance claim applies to product prior to the
application of a bolt-down kit.
Bolt-down kit contents (in select models only):
• 2 lag screws
• 2 washers
• 2 masonry anchors
Tools needed to bolt safe to the floor:
• Drill
• Wrench
• 7⁄ 16" (11 mm) drill bit – for drilling into the safe
• 9⁄ 32" (7.2 mm) drill bit – for drilling into a wood floor
• 3 ⁄ 8" (9.5 mm) drill bit – for drilling into a masonry floor
WARNING: • DO NOT drill from any location inside the safe.
• DO NOT bolt through the walls.
1
Tip the safe onto its right side (door hinges horizontal with the floor).
2
Unlock the safe and open the door.
Look to the bottom of the safe for
two indentations on the feet in
opposite corners. Using the 7⁄16"
(11 mm) bit; drill a hole through
each indentation perpendicular to
the bottom of the safe. DO NOT drill
from any location inside the safe.
3
Tip the safe upright, place the safe in the desired location and
open the door.
4
Use a screw or pencil to mark the floor
through both holes.
5
Move the safe aside to clear both marked spots for drilling.
6
Drill into the floor:
A
For wood: Using the 9⁄32" drill bit, drill
a hole 2-1⁄2" (64 mm) deep in each
marked spot.
B
For masonry: Using the 3⁄8" drill bit,
drill a hole 2-1⁄2" (64 mm) deep in each
marked spot. Install a masonry anchor
in each hole.
7
Replace the safe in the desired position, with the holes in the safe
aligned with those in the floor.
8
Securing the safe:
A
For wood: Pass each lag screw through a
washer, then through the safe and into a
hole. Tighten with the wrench.
F
B
For masonry: Pass each lag screw
F
through a washer, then through the safe
F
and into a masonry anchor. Tighten with
the wrench. Place masonry anchors into
F
the holes in the floor.
F
NOTE: • The safe should not be bolted to a wall, this will compromise
the fire rating. Drill holes through the feet only. DO NOT drill
through the back or sides.
• Bolting/unbolting the unit is at the consumer's expense and
discretion.
• Master Lock is not responsible for any costs incurred if the
unit is to be replaced.
4
Troubleshooting
THE PROBLEM:
WHY IT IS HAPPENING:
The door will not lock.
1. Shipping screw is in place.
2. Confirm that there is no obstruction in the door.
3. Bolted down incorrectly.
The handle is not
The clutch mechanism has
in the horizontal
been engaged.
position when the safe is
locked.
Cannot open door after
1. Safe doors equipped with a water-resistant
inputting the combination or
gasket may initially be tight.
electronic code.
2. Key lock is in the locked
position. (select models only)
The dial does
1. Shipping screw is still in place.
not turn.
2. Locking bolts are not fully extended.
Red indicator light blinks three
An incorrect code has been entered.
times and there are
three beeps.
Red indicator light blinks five
Keypad communication error.
times and there are five beeps.
Red indicator light blinks once
Program button is pressed out of sequence.
and there is one beep.
-or-
5 seconds has lapsed between button entries.
Red indicator light
An incorrect code has been entered three times
is blinking.
and system has entered delay mode.
Yellow indicator light is on.
Battery power is low. -or- Battery may be the
wrong type.
Limited Lifetime After-Fire
Replacement Program
If your Master Lock product is in a fire it will be sealed shut making
it necessary for it to be pried open. To help your family begin again,
Master Lock will ship a replacement free of charge. To be eligible for
the Limited Lifetime After-Fire Replacement Program you (the original
owner) must register your product by visiting masterlock.eu/safes.
THE SOLUTION:
1. Remove the screw on the back inside of the door.
2. Remove all items and accessories from inside the safe.
If this resolves the issue, re-set the accessories and
organize items to properly fit.
3. See page 4 for proper bolt-down instructions.
Rotate the handle up or down until it clicks into the
horizontal position.
1. Hold the handle up while inputting the code or dialing
the combination and then pull down on the handle.
2. If your safe is equipped with a key lock ensure that the
key is in the unlocked position. (select models only)
1. Remove the screw from the back of the door.
2. Ensure the handle is in the horizontal position.
Verify code and re-enter. If the programmable code you
are using doesn't work then use the factory code. If
successful re-program your programmable code.
Visit masterlock.eu/safes
Start over.
Wait two minutes and start over.
Replace with new alkaline batteries.
Got a question?
If you ever have any questions regarding your Master Lock product,
please visit our website masterlock.eu
WEEE Figure 1: In the European Union (EU), this symbol means that electrical and electronic
equipment should not be disposed of with general household waste. Please contact your dealer,
supplier or local recycling authority for further details regarding appropriate disposal of this product
and your nearest designated collection facility.
Figure 1
