Caroslide
When rebuilding for left side operation following
EN
instructions are very important
Tighten the three screws for the motor bracket to the lower plate by
using normal torque. Then tighten the two motor screws by using
a light torque. Wiggle the motor towards both sides within the play
admitted by the two screws. Fix the motor in the middle of the play
movement.
Tighten the screws by using normal tormal.
Drive the motor to an end position. Loosen the locking plates to
provide a position for the threaded axle that is free from strain. Make
sure trapezoid nut is tight to the plate.
Tighten the screws alternately using normal torque. Repeat the
procedure at the other end position.
