Silvercrest STHL 2000 C2 Bedienungsanleitung Seite 12

7. Display overview
38
30 TEMP Temperature is shown in the display.
The current room temperature is displayed when TEMP is permanently
lit.
The desired temperature is displayed when TEMP flashes.
31 OSC Swivel function is switched on.
32 Frost monitor function is switched on.
33 The operating panel button lock is active.
34 The Timer function is switched on.
35 The fan is switched on without heating.
36 Display of temperature and heat output levels
The current room temperature is displayed when TEMP is permanently
lit.
The desired temperature is displayed during setting when TEMP flashes.
The heat output levels L0 / L1 / L2 are displayed when they are set.
37 The heater is switched on.
38 Flashes when setting the desired temperature. Is lit when a temperature
is set and a heat output level is activated.
10 GB
30 31
37 36
32 33
34
35
