Memobase Plus CYZ71D Technical data
10.4 Power supply
10.4.1 Supply voltage
The PC powers the sensor(s) and MemoLink(s) via the USB cable and enables
the bidirectional transmission of Memosens data. An active USB hub must
have a power supply.
10.4.2 Power supply
• 5 V DC via USB
• Low power mode: max. 100 mA as per USB specification 2.0
10.5 Performance characteristics
10.5.1 Measured error
--> Documentation for the connected sensor
MemoLink only transmits data digitally so no measured data can be
corrupted. The measuring signal is converted to digital data in the sensor,
which means that MemoLink, the cable or PC software do not affect the
measured values.
10.6 Environment
10.6.1 Ambient temperature range
-10 to 50 °C (14 to 122 °F)
10.6.2 Storage temperature
-25 to 85 °C (-13 to 185 °F)
10.6.3 Relative air humidity
max. 85%, not condensing
10.6.4 Degree of protection
IP 65 (mated, i.e. when cables are plugged in) as per EN 60529
