Functional description
DC 5800 Turbo EX
Machine for suction and removal of dry, unhealthy, flammable, conductive dust according to dust class H in Zone
22.
The dust extractor is an electrically driven dust separator of robust design for use in connection with dust generat-
ing activities in the industry. Dust extractors are suitable for collecting inflammable dust in Zone 22. Industrial dust
extractors are intended for suction and removal of dust deposits. Explosion protection is provided by insulation of
the electrical parts and potential equalization of the components that come into contact with dust.
The machine can be used at temperatures between +10 and +40°C and is suitable for general cleaning.
Regular cleaning of the workplace is important to prevent dust explosions.
The dust extractor uses negative pressure (suction) to force the air through suction cover/nozzle, hose system, pre-
separator and dust separator. Coarse separation is carried out in the machine's cyclone, providing very effective
separation of any coarse dust. The fine dust is separated in the unit's filter cartridge. Reverse pulse filter cleaning
ensures extended filter life.
Always check that the electrical equipment and cables for the equalization are undamaged and that all accessories
are antistatic. Connect the plug to an electrical socket outside the zone with voltage as specified on the machine's
marking.
The material is separated into a container attached directly to the cyclone. The filter is cleaned using reverse pulse.
The separated and filtered material is collected into a container with a plastic sack insert, see consumables. The
container can easily be removed from the machine by releasing the fasteners, which makes it easy to take the
material away.
ATEX This machine with accessories is suitable for use in Zone 22 (2014/34/EU) for suction and removal of:
This standard covers the safety of dust extractors with electric motors, including dust separators and back-pack
vacuums, used for wet extraction, dry extraction or wet-and-dry extraction, supplied for commercial use indoors and
for outdoor use with and without accessories for the collection of combustible dust in an atmosphere (Zone 22)
designated as explosive.
CAUTION
The machine contains hazardous dust. Emptying and maintenance operations, including remov-
al of the dust extraction container, must only be carried out by qualified personnel who must
wear appropriate protective equipment. Do not use the unit without the entire filter system in
place.
