COMPACT N&D
EN
Take care not to invert polarities when connecting the unit to the power supply. If this were to happen,
the unit will not work and irreparable damage will be caused to the compressor modules.
Centrifugal
blower
wiring communication
Az Blue
N Black
R Red
V Green
B White
A Yellow
Na Orange
M Brown
Compressor
electronic
module
Compressor
IMPORTANT NOTE!
Electronic
board
28
Electric wiring
Return
air sensor
Anti-freeze
sensor
Point "A"
fuse box
making the
Condenser fan
original mass
Compressor
electronic
module
Compressor
®
