Improper running of the belt (belt guiding) may destroy the shutter belt and cause un-
necessary strain on the product. Install the product such that the belt enters the shutter
belt drive as vertically as possible. This will avoid unnecessary friction and wear.
Any other or further utilization beyond the explicitly specified shall be regarded as
not intended use.
Alfred Schellenberg GmbH shall not be liable for any consequential damage, pro-
perty damage and personal injury due to improper use.
According to EN 13659, it must be ensured that the displacement requirements as
per EN 12045 are met. When unrolled, the displacement at the lower edge must be
at least 40 mm at an upward-directed force of 150 N. It must be ensured that the
travel speed of the hanging must be less than 0.2 m/s in the last 0.4 m.
IMPROPER USE
The use of the product for applications other than the aforementioned is not permit-
ted.
Using this product outdoors presents a risk of death from short circuit or electric
shock.
Never install or operate the product outdoors.
Mechanical locks of any kind are not suitable for automated operation with this
product.
TECHNICAL DATA
Item number
Power supply operating voltage
Rated output
Standby output
Power supply output
Torque
22745/22638
230 V AC / 50 Hz
29 W, max. 45 W short term
approx. < 0.7 W
24 V DC / 1.2 A
MdN = 2.5 Nm
