In order to turn the device off with the IR remote control after use, please press the BLACK OUT button.
After switching the device on again, it will continue with the same program it was processing when switched
off.
CLEANING AND MAINTENANCE
We recommend a frequent cleaning of the device. Please use a soft lint-free and moistened cloth. Never use
alcohol or solvents!
There are no serviceable parts inside the device except for the fuse. Maintenance and service operations are
only to be carried out by authorized dealers.
Replacing the fuse
If the fine-wire fuse of the device fuses, only replace the fuse by a fuse of same type and rating.
Before replacing the fuse, unplug mains lead.
Procedure:
Step 1: Unscrew the fuseholder with a fitting screwdriver from the housing (anti-clockwise).
Step 2: Remove the old fuse from the fuseholder.
Step 3: Install the new fuse in the fuseholder.
Step 4: Replace the fuseholder in the housing and fix it.
Should you need any spare parts, please use genuine parts.
If the power supply cable of this device becomes damaged, it has to be replaced by authorized dealers only
in order to avoid hazards.
Should you have further questions, please contact your dealer.
TECHNICAL SPECIFICATIONS
Power supply:
Power consumption:
Number of channels:
DMX-512-connection:
Number of LEDs:
Beam angle:
Maximum ambient temperature T
Maximum housing temperature T
Minimum distance from flammable surfaces:
Minimum distance to lighted object:
Fuse:
Dimensions (LxWxH):
Weight:
DANGER TO LIFE!
Disconnect from mains before starting maintenance operation!
:
a
:
B
230 V AC, 50 Hz ~
20 W
3
3-pol. XLR
192 5mm
25°
45° C
60° C
0.50 m
0.10 m
F 0.5 A, 250V
340 x 290 x 330 mm
5.5 kg
24/25
00031787.DOC, Version 1.0
