Rotfuchs EWR3000 Originalbetriebsanleitung Seite 21

Figure 1
3. Check the direction of the drum turning.
Pull and turn the clutch knob to the "Off" position (drum can be turned freely by hand). Pull out
the cable from the drum, then engage the clutch by turning the knob to the "In" Position. Push
the "Cable In" button on the handheld. If the cable is re-spooling then you connected the winch
the right way. Otherwise please swop the line-connections and repeat the above mentioned
steps.
7.2 Operation
1. Pull and turn the clutch knob to the "Off" position, so the drum can be turned freely by hand.
2. Grab the cable assembly hook and pull the cable to the desired length.
Then attach to item that is to be pulled.
Warning! Check that there are at least five turns of wire rope left on the drum
before starting operation.
3. Engage the clutch by turning the clutch knob to the "In" position.
Warning! Clutch must be fully engaged before winching. Never engage clutch
knob while drum is turning. The clutch knob has been adjusted and perma-
nently locked in place with a thread locking compound at the factory. Do not
attempt to re-adjust the knob.
4. Push and hold the "Cable In" button on the handheld. The cable rope is re-spooled.
Push and hold the "Cable Out" button to reverse direction. Wait until the motor stops before
reversing directions.
5. Always re-spool the cable rope after finishing operation.
21
