6. Troubleshooting
SYMPTOM
Motor will not operate or runs
in one direction only
Motor runs but drum does not
turn.
Motor runs but with insuffici-
ent power or line speed
Motor overheading
7. Installation
7.1
Mounting your winch
1. Mount the winch on the vehicle or other object using Screw M8 x 30, Lockwasher and
Washer-Flat offered. Other similar screws can be used instead.
Warning: The winch must be mounted with the wire rope in the underwind direction. Improper
mounting could damage your winch and void your warranty.
Attention! The winch must be mounted with the wire rope in the direction of the
wind. Incorrect installation can damage your winch and void the warranty.
2. Route the two couple of lines from the switch to the motor and battery respectively. Connect
the red line to the positive (+) terminal and the green (or black) line to the negative (-) terminal
of the 12V Battery. Connect the rest two lines to the terminal on the motor of the electric winch
(Figure 1)
POSSIBLE CAUSE
•
Switch inoperative
•
Broken wires or bad
connection
•
Defective motor
•
Clutch not enganged
•
Weak battery
•
Defevtive motor
•
Winch running time too
long
•
Defective Motor
20
SUGGESTED ACTION
•
Replace switch
•
Check for poor connec-
tions
•
Replace or repair motor
•
Engange clutch
•
Recharge or replace bat-
tery.
•
Check battery terminals
for corrosion. Clean as
required.
•
Check and clean connec-
tions.
•
repair or replace motor
•
Allow winch to cool down
periodically
•
Repair or replace motor
