5. Description with Illustration
Its winch has been designed to tow loads and consists of the following components:
1.
Motor
2.
Stationary Gear Housing As-
sembly
3.
T-Series Carrier Assembly
4.
T-Series Rotator Gear
5.
Drum Support Plate
6.
Pan Head Screw M4x12
7.
Drum Support Bushing
8.
Clutch Assembly
9.
Spring
10.
Drum Assembly
11.
Screw M5x5
12.
T-Series Bushing
13.
Thick Flat Washer
14.
Hex Flange Nut M5
15.
T-Series Baseplate Assembly
16.
Tension Plate
17.
T-Series F/W Knob Assembly
1x
18.
Elastic Pin 2.5x14
1x
19.
Sechskantschraube M6x16
1x
20.
Hex Skt FH Screw M6x16
1x
21.
Screw M8x30
1x
22.
Washer-Flat Ø8
4x
23.
Lock Washer Ø8
1x
24.
Nut M8
1x
25.
Red Strap
1x
26.
Switch Assembly
1x
27.
Cable Assembly
1x
28.
Tie Bar (2000lbs not need it)
1x
29.
Control Box
1x
30.
Relay
2x
31.
Wire
1x
32.
Wireless Switch
1x
1x
17
