5. Right Armrest Assembly Drawing
2 1
6. Footrest Assembly Drawing
2
1
12
20
19
18
17
Translations of the Original Operating Instructions into other languages can be found at www.donnerberg.net.
14 13
12 11 10
6
4
3
5
10
11
14
15
16
No� Name
1 Armrest Decorative cover - Right
2 Armrest assembly - Right
5
3 Small Decorative cover - Right
4 LED cover - Right
5 Upper Decorative cover - Right
6
6 Quick Control buttons
7
7 Quick Control silicone buttons
8
8 USB Cover
9
9 Quick Control PCB
10 LED Fixing base - Right
11 LED Plate
3
12 Logo Sticker
13 Speaker Cover - Right
14 Speaker Inner plastic cover - Right
No� Name
1 Kneading Side plastic - Right
7
8
2 Kneading Side plastic - Middle
3 Kneading Side plastic - Left
4 Kneading Locating frame
5 Kneading Locating seat (Left / Right)
6 Kneading assembly
7 Eccentric Bearing Seat upper cover
9
8 Rear Calf-Rest protective cover
9 Calf-Rest support plate
13
10 Driving Shaft
11 Footrest Telescopic Slip - Lower
12 Footrest Telescopic Slip - Upper
13 Rear Footrest protective cover
14 Spring
15 Footrest Expansion tubes
16 Caster
17 Footrest plastic cover
18 Foot Roller frame
19 Foot Roller Assembly
20 Footrest plastic
