PRODUKTBESCHREIBUNG
3.5.2.1 UL Satisfaction Ratings
3.5.3 Erdung
10 B E T R I E B S A N L E I T U N G | WI180C-PNS01
The total control output current and ambient temperature will be retricted as follows
depends on the number of sensors (proximity switch) connected to the programmable
controller.
Up to 3 units:
Input
Output
Maximum surround air Temperature +55°C.
Up to 8 units:
Input
Output
Maximum surround air Temperature +50°C.
Up to 16 units:
Input
Output
Maximum surround air Temperature +45°C.
Das Gerät wird mittels Federkontakt über die Hutschiene geerdet:
12 - 24 V dc, max. 1.02 A, Class 2
12 - 24 V dc, max. 0.45 A, Class 2
12 - 24 V dc, max. 1.02 A, Class 2
12 - 24 V dc, max. 0.8 A, Class 2
12 - 24 V dc, max. 1.02 A, Class 2
12 - 24 V dc, max. 0.8 A, Class 2
