Simons Voss Technologies SmartLocker AX LockNode Kurzanleitung Seite 45

45 / 76 | EN
4. Pull the optical fibre out of the reader.
4
5. Using needle-nosed pliers, disconnect the plug of the
cable below the circuit board.
5
6. Turn the reader 60° anti-clockwise (bayonet mount).
6
7. Remove the reader from the D socket.
7
8. Undo the four screws from the circuit board mount to
separate the circuit board mount from the reader base.
8
9
9. Open the FPC connector folding mechanism on the LNI.
10
10. Insert the reader's non-assigned connection into the
open FPC connector.
11
11. Close the FPC connector's folding mechanism.
12
12. Screw the circuit board mount and the reader base back
3. Installation
