EN
3 RECIRCULATION INSTALLATION
With recirculation, a return opening of at least 550 cm²
must be provided in the kitchen furniture in order to
blow the cleaned air into the kitchen.
The return opening can be made by making a cut-out
in the plinth or by fitting a grille.
For optimum performance of the hood it is important
to pay attention to the items mentioned below.
General:
− Make the duct as short as possible and with as few
as possible bends.
− Avoid square bends. Use rounded bends for proper
air conduction.
− Make sure that sufficient air is supplied. Fresh air
can be supplied by slightly opening a window or an
outside door or by installing an inlet grate.
− Use tape for airtight connections.
