3a. Diagram of overall installation
p O
R
H
P
Pump
3. INSTALLATION
H-Power
electrical cabinet
Probe holder
for glass and
Goldline probe
Filter
AquaRite UV LS
®
Only use spare parts supplied by Hayward brands
AquaRite UV LS
®
Heat pump
UV Module
Page 5 on 22
®
Wi-Fi
module
Peristaltic
pump
pH probe
Rx probe
Flow switch
Probe- Transparent
holder
Earthing Température
anode probe
cell
