7. Operations and warranty conditions 7. Operations and warranty conditions
7.1 Operation conditions
For reliable function of the tool we recommend to use treated compressed air.
treated compressed air means compressed atmospheric air bare of solid particles
and water, reduced to required pressure and lubricated with anti-corrosive oil.
Immediately before the tool there must be a regulation valve set to maximum
outlet pressure of 0.7 MPa, air filter and lubrication in the circuit of compressed air.
Sound-pressure level of impulse noise L
pAI
recommended to use ear protectors during continuous and long-term operation.
Average overall vibration total effective value a
The trigger enables safe control of the tool with a force max. 10 N < 50 N without
releasing the griphandle according to the health regulation.
7.2 Warranty conditions
For reliable and safe function of the tool it is necessary to adhere to instructions
and principles stated above.
For the warranty period the customer must not perform any alterations other
than those permitted by the manufacturer, see paragraph 2.1, 3.1, 3.2. other
non-detachable parts are secured with paint. In case of neglecting this protection
the manufacturer shall not admit possible warranty repairs. To admit warranty
repair the customer must submit proof of purchase [invoice]. The warranty period
is 24 months from the day of purchase if the purchase contract does not state
otherwise.
Warranty is valid provided that the following:
> General General safety instruction and principles [paragraph 1]
> Tool operation [paragraph 2.4]
> Daily and weekly maintenance [paragraph 3.1 and 3.2]
> Storage [paragraph 5]
> Operations and warranty conditions [paragraph 7]
Warranty does not apply to quickly expendable parts [see paragraph 4.2].
10
does not exceed 85 dB(A), still it is
= 1,5 m.s .
2
hv,8h
8. CE Certification 8. CE Certification
EC Declaration of Conformity
We hereby declare that, when used in accordance with the manual, the pneumatic
blind rivet nut tool AS-4 conforms to the following standards and stated technical
documentation:
> Production documentation of Rivet Factory Group s.r.o.
> Requirements to the Administrative direction no. 176/2008 Coll. compatible with
EU Directive 2006/42/EC
> ČSN EN ISO 11148-1:2015
> Assessment Report No. VVUÚ-021009/2022 dated 11.07.2022 issued by VVUÚ, the
Certification Body for Products
Conformity was assessed in cooperation with the testing laboratory in VVUÚ
a.s. Ostrava-Radvanice [notified body number 1019, registered by European
Commission] which issued certificate for this product type No. VVUÚ-231/N/2022
dated 11.07.2022.
For the latest version of the CE Certificate you can contact the manufacturer or
your sales agent.
Authorised representative:
Qonnect B.V.
Europalaan 12
6199 AB Maastricht Airport
The Netherlands
Daan Schrijen,
Managing Director
AS-4
