TOURING RALLYE RACING
01-040-0660-0
Contains:
1 x Universal GPS mount adapter
2 x Spacer short
2 x Spacer long
2 x Screw hex internal M6x40
2 x Screw hex internal M6x50
1 x Screw short hex
1 x Lock washer
2 x Washer M6
Note:
This adapter is a universal design. Some motorcycles may require hardware that are not
included in the kit.
Installation:
Loosen the stock brake or clutch lever clamp screws.
Set two screws with washers through the elongated holes on the adaptor lower part and then slide
spacers on the screws behind the adaptor.
Choose appropriate spacer and screw set so that the thread depth of the screws tightened is
equal to stock screws. Tighten bolts to 12Nm
Install now the Touratech GPS mount on the top adapter bar.
Attach then the top bar on the lower adaptor part using supplied short hex screw and lock washer
(see arrow) and tighten it with the supplied tool.
These instructions are at our current level of knowledge. Technical issues subject to change. Legal requirements do not exist.
TECHNOLOGY
Installation Instruction:
Universal GPS Adapter
