DMX ERROR Choose SAVE in order to save the last DMX data
incase of DMX signal error. Choose BLACK in order to blackout in
case of DMX signal error.
PERFORM...this setting allows the user to select the performance
characteristics of the fixture.
LIVE mode is the default mode which balances the requirements
of output and noise.
STUDIO mode maintains extremely low noise at all times and
operates at a moderated power level.
POWER mode operates at high power for long periods of time
without making considerations for noise levels.
PWM_RATE is PWM reflesh rate bottom, press UP/DOWN to
choose 600 HZ; 1200 HZ; 2000 HZ; 4000 HZ; 25000 HZ
NOTE: WITH REFLESH RATE INCREASED, GRAY RATE OF DIM-
MER WILL BE REDUCED, (THAT'S MEANS HIGH REFLESH RATE,
LOW GRAY RATE), WHEN IT'S 4000HZ, CV3 IS INVALID, WHEN
IT'S 25000 HZ, CV1, CV2, CV3 ARE INVALID, SO PLEASE LOWER
PWM RATE TO INCREASE GRAY RATE IN NECESSARY.
FULL POWER CCT is the color temperature choose bottom, press
UP/DOWN to choose, under full power, 3200 K, 4200 K, 5600 K
can be chosen, when choose COLOR, 3200K, 4200K, 5600K are
not work, but choose NORMAL.
MENÜ
MENU
SETTING ***** UPLOAD
RESET
COLOR
DIMMER
SEND
DMX ERROR
PERFORM
PWM_RATE
FULL POWER CCT
**** SEND
**** RESET
UC
OFF
RGBTOW
DIM4
DIM3
DIM2
DIM1
OFF
YES
NO
SAVE
BLACK
LIVE
STUDIO
POWER
600 HZ
1200 HZ
2000 HZ
4000 HZ
6000 HZ
25000 HZ
3200 K
4200 K
5600 K
10000 K
NORMAL
