ACTIVATE THE PASSWORD
3.8
Enter the KEY mode to select whether the access password is on
or off. When the fixture is set as PASS ON, after 30 seconds or turn
on the fixture next time, the fixture will need an access password
to enter the display menu control.
NOTE: PASSWORD UP+DOWN+UP+DOWN+ENTER
MENÜ MENU
KEY
3.9 BALANCE PARAMETERS AND CORRECTION
MENU DISPLAY
Enter the correct password UP + DOWN + UP + DOWN + ENTER to
go to CALIB.C Menu.
Enter the CALIB.C to select white color of different color tempera-
ture. There are 13 pre-programmed White colors can be edited by
using RED, GREEN, BLUE, AMBER and LIME.
Enter the RGBtoW to adjust the RGB parameter to make different
whites. When the new setting is activated, the DMX controller
choose RGB = 255,255,255 the white color will be made by the
values on the RGBtoW.
MENÜ MENU
CALIB C.
INFO
3.10
Use INFO menu to check VERSION of firmware as well as RDM
UID and LABEL.
MENÜ
MENU
INFO
ON
OFF
***** WHITE
RGB TO W
VERSION V01
RDM UID
LABEL
WH. 01 2700 K
WH. 02 3000 K
WH. 13 10000 K
R. (0-255)
G. (0-255)
B. (0-255)
0X38A00006B36
LED-FRESNEL
