Go® Maxi Frame Reclining System
A. Main seat
B. Retention system harness
B1. Safety buckle
B2. Height strap adjusters
B3. Central strap adjusters
B4. Retention system adjustment hole
C. Safety belt for bicycle frame
C1. Safety belt buckle
C2. Safety belt retainer
D. Center of gravity
E. Footrest
E1. Footrest lever
E2. Footrest peg
E3. Footrest strap
F. Traceability information
This product contains small parts like bolts, plastic bags, and small packaging hangers. Keep them out of
reach of children to avoid suffocation hazards.
• This child bicycle seat must not be mounted in
folding bicycles.
• This child bicycle seat must not be used on EPAC /
Pedelecs above 25 km/h / 15,5mph.
• This child bicycle seat must not be mounted to
bicycles fitted with rear shock absorbers.
• This child bicycle seat must not be mounted to
motorized vehicles such as mopeds, scooters.
• This child bicycle seat must be assembled on
bicycles with round and oval frames with diameters
ranging from Ø28 to Ø40 mm.
• The child bicycle seat must be assembled on
bicycles with wheels with diameters of 26" and 28".
• This child bicycle seat is only suitable for carrying
children with a maximum weight of 22 Kg, and a
maximum height of 110 cm, (and children with
recommended ages ranging from 9 months to
6 years of age - with the weight and height as the
decisive variable).
• The total weight of the cyclist and the child
transported must not exceed the maximum
permitted load permitted for the bicycle. Information
Specific Instructions for Mounting the Seat in the Bicycle
1. Cut the plastic straps that hold the mounting block
(I) and others.
2. Use the allen key No. 5 (I5) to loosen the screws
(J1). Desingage the metallic support bar holder/
Go® Maxi Frame
Table of Contents of Product
ATTENTION
Specific Instructions For Mounting
EN.
G. Metallic support bar holder/ mobile stand
H. Metallic support bar
I. Frame holder
I1. Screws M8
I2. Plastic mounting block
I3. Release button
I4. Metallic mounting plate
I5. Allen key no. 5
I6. Lock washer M8
I7. Safety device indicator
I8. Protective rubber
J. Metallic mounting plate
J1. Screws M8
K. Reclining button
L. Reclining system plate
on the maximum load can be found in the operating
instructions of the bicycle. You can also contact the
manufacturer for this question.
• The seat may only be mounted on a bicycle suitable
for the attachment of such additional loads. Please
consult your bicycle instructions manual.
• The position of the child bicycle seat must be
adjusted so that the bicycle rider does not touch the
child bicycle seat with the feet when in motion.
• It's very important to adjust correctly the seat and
its component parts for optimum comfort and safety
of the child. It's also important that the seat does not
slope forward, so that the child does not tend to slide
out of it. It is also important that the backrest slope
backward slightly.
• Check if all parts of the bicycle function correctly
with the child bicycle seat mounted.
• Check the instructions of the bicycle, and If you
have any doubts on fitting the child bicycle seat to
your bicycle, please contact your bicycle supplier for
further information.
mobile stand (G) by pulling it backwards. After
removing this part (G) you will no longer need to use
it, so we give it a functional purpose – you can keep it
and use it as a mobile stand.
