Device Overview; Setting Bench Sb1 - Garant Setting Bench Sb1 Betriebsanleitung

3.

Device overview

3.1.

SETTING BENCH SB1

13
12
11
10
9
1 On/Off switch
2 Movement axis with covering strip
3 Moveable ceramic gauge block, mounted on a slide
4 Fixed ceramic gauge block
5 Name plate
6 Solid granite base
7 Adjustable feet with screw threads
1
2 3 4
8
8 Thread
9 Screws for securing the transport restraints
10 Ports for connecting data and power
11 Emergency stop switch (safety device)
12 Monitor mounting arm
13 Monitor with touch screen controls
5
6
7
