3.- Connection to the ducted unit
- Through gateway: Connect the communication gateway to the AC unit port of the main control board
connect it to ducted unit,
thermostat of the unit. For the connection of DIN rail gateways, use (2x0.22 mm
- Through Start-Stop: Use the main control board relay
manufacturer's instructions. I
4.- Other peripherals (AZCE6OUTPUT8, AZX6CCP
You can find the instructions on how to connect and configure other peripherals on their data sheets.
5.- Powering the system
Use the power input to power at 110/230 Vac
and any others control elements that require it. Use the appropriate
cable (3x1.5 mm²). For added security, secure the wires using the turret.
According to the current local and national regulations, it is mandatory to add a switch (or other element to
Important:
disconnect the system) to the external supply wiring so that a constant separation between poles is guaranteed. The system
will restart automatically if the supply is eventually turned off.
the power supply.
Once all the connections are made, make sure you replace the cover properly.
Remember:
follow the instructions of the communication gateway
1 A, V 24 / 48 Vdc.
max max
the main control board
) Airzone wire.
2
to perform the start-stop of the unit following the
Use an independent circuit from the controlled system for
. In order to
. It is recommended to install the
