Fronius OPT/i WF PushPull Installationsanleitung Seite 13

Connecting the
leads to the PC
X1
board
X2
And finally...
1
3
TX 20
X7 X9 (POE) X6
Using the cables included in the
1
scope of supply, establish the con-
nections according to the circuit
diagram
2
SW 7 mm
4
3
2 x
3 Nm
TX 25 / 5x10 mm
13
