Forst Outdoor Sofa Swing Assembly Instructions
3) Table of Contents
#
Designation
1.
2.
Base cover
3.
Center strut
4.
Side part
5.
Cross strut
6.
Clamping lever
7.
Wood slat
8.
Assembly aid
9.
Chipboard screws A2
10.
Cylindrical screw
11.
Washer
12.
Cylindrical screw
13.
Lock nut
14.
Washer
15.
Hexagon screw
Base
4,5x25 mm
Techn.
Quantity
info
1
1
1
2
3
1
26
2
104
8x20 mm
4
8 mm
4
10x30 mm
4
4
10 mm
8
20x80 mm
1
Illustration
I
-13-
