Technical data and functional description
2.1
Technical data
Article
Model
11100064
AV3008
11100065
AV3010
11100074
AV3708
11100075
AV3710
11100084
AV4508
11100085
AV4510
11100094
AV5508
11100095
AV5510
* Measured according to ISO 1217; ** Measured according to ISO 3744
2.2 General description
The AV-Series oil-filled screw compressor series is designed for uninterrupted and efficient
compressed-air production.
The AV-Series compressor is an electric motor-operated, intake-regulated, belt-driven and air-
cooled compressor, enclosed in a sound-insulated canopy. An electronic controller pro-Log with
an LCD indicator panel is provided, including start and stop buttons and an emergency stop
button. Pressure and temperature relays are used for system control and protection.
COMPRAG
Screw air compressor AV-Series
Entitlement to free handling of faults arising during the guarantee pe-
riod is forfeited when:
- No warranty service coupon for the compressor or it is filled out in-
correctly
- No records for the compressor's scheduled maintenance are entered
in the compressor's service book
- Unoriginal parts and lubricants are used
Drive power,
Max. operat-
compressor
ing pressure
(kW)
(bar)
5-8
30
5-10
5-8
37
5-10
5-8
45
5-10
5-8
55
5-10
Rated
Output*
voltage,
(m
/min)
compressor
3
(phase/V/Hz)
4,70
4,00
5,90
5,10
3/380/50
7,00
6,20
8,70
7,70
Noise**
Screw
(dB)
connection
72
1-1/4"
72
75
1-1/2"
Oil
capac-
ity***,
liter
15
20
9
