Aidoo Pro connects to the air to water unit via the Modbus communication cable provided.
The control and configuration of this device is carried out via Bluetooth and Wi-Fi Dual (2.4/5
GHz) from the "Airzone Cloud" app (available for iOS and Android). An external power supply is
required to power your Aidoo Pro device.
Note: for more information about our products, visit airzonecontrol.com.
DEVICE ELEMENTS
Port
Connection to
RS-485
indoor unit
Factory reset
This button allows you to restore the device to factory settings by pressing it continuously for
more than 10 seconds.
Reset of the device
Allows you to reset the device without removing any previously set configuration parameters.
RS-485 port
RS-485 port for establishing Modbus RTU or BACnet MS/TP
communication with the device.
Factory
reset
Digital
Diagnostic
input
LEDs
Power Supply
Reset of
the device
Relay
output
Power supply
input
Modbus communication
cable with the unit
