5 Front Guard Installation
5.1 Align screw holes on the outer ring of both the front and rear guards,with the
positioning clip aligned as illustrated.
5.2 Press down all the buckles to fasten the front guard with the rear guard. at the
screw holes, tighten the separated screw and nut.
6 Tilt angle adjustment
Manually adjust the back cover of the motor up and down to adjust the pitch angle of
the fan.
7 Oscillation control
To make the fan oscillate, push down on the oscillation knob located on the top of the
motor housing. To stop the fan from oscillating, pull up the oscillating knob.
Tilt Adjustment
Manual
Pull-up for static
Push-down to swing
Swing Pull-knob
08
Buckle
EN
