Ardo CALYPSO PRO Gebrauchsanweisung Seite 27

Electromagnetic Compatibility (EMC, IEC 60601-1-2, Table 6)
Recommended separation distance between portable and mobile RF communications equipment and
Calypso Pro
Calypso Pro is intended for use in an electromagnetic environment in which radiated RF disturbances are controlled. The
customer or the user of Calypso Pro can help prevent electromagnetic interference by maintaining a minimum distance
between portable and mobile RF communications equipment (transmitters) and Calypso Pro as recommended below,
according to the maximum output power of the communications equipment.
Rated maximum output
power of transmitter
[W]
0.01
0.1
1
10
100
For transmitters rated at a maximum output power not listed above, the recommended separation distance d in meters
[m] can be estimated using the equation applicable to the frequency of the transmitter, where P is the maximum output
power rating of the transmitter in watts [W] according to the transmitter manufacturer.
At 80 MHz and 800 MHz, the separation distance for the higher frequency range applies.
NOTE 1
These guidelines may not apply in all situations. Electromagnetic propagation is affected by absorption and
NOTE 2
reflection from structures, objects and people.
Separation distance according to frequency of transmitter
[m]
150kHz to 80MHz
0.04
0.11
0.35
1.11
3.5
80MHz to 800MHz
0.04
0.11
0.35
1.11
3.5
800MHz to 2.5GHz
0.07
0.22
0.7
2.21
7
27
