STRUCTURE ILLUSTRATION

Refrigerator rollbond
evaporator
Shelf
Steel column
strip
Levelling foor

INSTALLATION

IMPORTANT: The installation of the device requires the intervention of 2 people.
This refrigerating appliance is not intended to be used as a built-in appliance.
Recommendations:
The location you choose for your beverage cabinet must be:
- free and well ventilated;
- far from any source of heat and direct sunlight;
- not be too wet (laundry, pantry, bathroom etc.);
- have a flat floor;
- obtain a reliable and standard electricity supply;
- Avoid direct sunlight and heat sources such as stove, heating radiator, etc. If
the cooler has to be put next to heat source, a suitable insulation board shall be
applied or keep the cooler away from heat source.
The device is designed for the climate class SN/N/ST. Protect the unit from heat
(above 38°C) and cold (below 10°C), dust, moisture, water and splash water.
Location
The top space of the cooler shall be greater than 300mm,and the distances
from bothsides and backside shall be more than 100mm to facilitate heat
dissipation.
300mm
100mm
- 25 -
Door Handle
Temperature-control
knob
100mm
