DESCRIPTION OF THE DEVICE

This user manual describes the model BAR-6 as a reference. Illustrations and features of the other model
are comparable.
1
(1) Safety eyelet
(2) RGB/WW LED
5 6
(5) Power input
(6) Fuse holder
(7) DMX input
(8) USB port for QuickDMX wireless receiver
2
7 8
(3) Fixation screw
(4) Mounting bracket
9
(9) Display with operating buttons
(10) DMX output
(11) Power output
21/32
3
4
10 11
00145385, Version 1.0
