TRANSPORT & INSTALATION
5. TRANSPORT AND INSTALATION

5.1 Transportation of chair

WARNING!
Risk of impact or crushing while lifting and transporting the chair.
The must not be any items or persons on the chair during transportation.

5 1 1 Preparations before transport

• T he electrical supply connections are on the bottom of the chair.
• Define the space for setup.
• Define way of transportation and remove possible obstacles.

5 1 2 Transportation

Ideally transport the chair with a lifting truck.
1. Lift the chair carefully and as little as possible. Keep the chair balanced!
2. Move the chair as close to the floor as possible to the designated space.
3. Lower the chair slowly.
4. Transport the two boxes separately because of safety reasons.
Chart 6: Transport of the chair
48

5.1.3 Unpacking

Improper opening of the package can damage the chair!
Open the package following these steps:
1. Place the box on the ground as indicated by the symbol on the box.
2. Flip the box to one side and open the bottom of the box.
3. Flip the four bottom parts completely to the outside.
4. Slowly flip the box back to its former position.
5. Lift the box off the chair.

5 1 4 Moving the chair

Take the length of the electric cable into account when moving the chair.
Disconnect it from the power outlet if necessary. Store the cable in the side pockets for moving.
HINT!
TOPRO participates in the recycling of the packaging material. Through
its participation TOPRO reduces the emission of greenhouse gasses.

5.2 Montage

The assembly is being done by the certified dealer on site.
HINT!
For ergonomically reasons TOPRO suggests the assembly is done by
two persons.
WARNING!
Risk of fatal injury from electric current!
The covers and enclosures must not be opened, removed or damaged.
The chair has to be disconnected from power during installation.

5 2 1 Connections of the components

Electric components
• Avoid creating obstructions or tripping points with the wire.
• Protect the cable from damage.
