Technical Data:
Model Number
Connection
AS-Interface
Inputs
Inputs
OFF I
[mA]
In
ON I
[mA]
In
U
OUT
I
[mA]
OUT
Operating voltage U
B
Operating current I
[mA]
e
Indicators
4, Switch status (I1...I4=1)
Power (AS-Interface)/sensor
overload*
EMV per
Operating temperature t
[°C]
b
Storage temperature t
[°C]
l
Protection (IEC)
Allowable shock and
vibration
Weight
* If the sensor current consumption is greater than I
indicating a short circuit and the module is no longer active on AS-Interface.
Description
The VAA-4E-G4-ZE is an AS-Interface coupling module with four inputs. Mecha-
nical contacts and 2- and 3-wire sensors can be connected to the inputs. The IP67
rated module features completely encapsulated electronics. The robust housing is
ideal for applications where heavy vibration may be encountered such as valve
positioning and actuation.
Sensors attach to PG cable glands and cage tension spring terminals. LEDs indi-
cate the current switch status of each channel and display the AS-Interface voltage
and power supply status.
Both flat and round cables can be used for the AS-Interface network. Use the U-
G1F or U-G1FF base for AS-Interface flat cable or the U-G1P or U-G1PP base for
round cable. The AS-Interface standardized base U-G1FF (EEMS) uses the ca-
ble-piercing method to connect both the yellow and black flat cables.
Note: The mounting base for the module is sold separately.
Subject to reasonable modifications due to technical advances.
2
Pepperl+Fuchs Group · Tel.: Germany (6 21) 7 76-11 11 · USA (3 30) 4 25 35 55 · Singapore 7 79 90 91 · Internet http://www.pepperl-fuchs.com
VAA-4E-G4-ZE
cable-piercing technique or terminal
compartments
yellow flat cable or standard round cable
PG7 thread and spring tension terminals
four 2- or 3-wire sensors, DC, sourcing
≤ 1
≥ 4.5
[V]
20 ... 30
≤ 160, short circuit protection (per module)
via AS-Interface, reverse polarity protection
≤ 40
LED yellow
LED green/LED red
EN 50 081-2, EN 50 082-2
-25 ... +60 (-13 ... +140°F)
-25 ... +85 (-13 ... +185°F)
IP 67
screw mounted: b ≤ 30 g, T ≤ 11 ms
snap-on mounted: b ≤ 15 g, T ≤ 11ms
screw mounted: f ≤ 55 Hz, a ≤ 1mm
snap-on mounted: f ≤ 55 Hz, a ≤ 0.5mm
[g]
180
, the red LED will illuminate
OUT
Programming Instructions
Address
preset to 00, can be changed via
the bus master or with a handheld
programmer.
IO-Code
0
ID-Code
0
Programming Instructions Bit Assignment
Data Bits (outputs via AS-Interface)
Bit
Function
D0
input I1
D1
input I2
D2
input I3
D3
input I4
Accessories
U-G1F
Base for connection of 2 AS-Interface flat cables
U-G1FF
Base for connection of AS-Interface (yellow) and
24 V DC (black) flat cables
U-G1P
Base for connection of two round cables for AS-Inter-
face communications
U-G1PP
Base for connection of AS-Interface and 24 V DC
round cables
VAZ-G4-B
Splitter
VAP-HH1
Addressing device
∅
9,6
∅
5,3
66
