Connections

Power supply TKS 3000A is powered with AC Mains, 230V 50 Hz.
AC Mains connection The AC Mains side of the regulator is galvanic isolated from the controller part.
One input for AC Mains 230V 50 Hz.
One output for controlling max. two 230V AC fans, max load <5A, internally fused with
6,3AT (ant surge) fuse.
One output for electrical heater, max load 6A.
Two potential free relay outputs for controlling two AC cooling units. Max load 3A.
Two outputs for controlling of 230V AC damper motors.
Input Mains 230V AC
50Hz
Speed controlled output
for 230V AC 50Hz fan
motors. Phase-angle con-
trol
Output for controlling of
external heater, max 6A
Output for potential free
control of two AC-units.
(Relay closure when AC
active, max 3A).
If only one AC is used,
connect it to the AC1
output.
Output1 for steering
230VAC damper motors.
(Line is connected to D13
when damper is activated.
Intake/exhaust dampers.
Output2 for steering
230VAC damper motors.
(Line is connected to D23
when damper is activated.
TC dampers.
Description Marking
- LINE -
FAN MOTOR
-HEATER-
-Cooling-
-DAMPER 1-
-DAMPER 2-
Function
230 V AC Line
230V AC Neutral
230 V AC PE
230 V AC Line
230V AC Neutral
230 V AC PE
230V Electrical heater L
230V Electrical heater N
230 V AC PE
AC1 potential free relay output1
AC1 potential free relay output2
230 V AC PE
AC2 potential free relay output1
AC2 potential free relay output2
230V AC Line to damper motor1 D11
230V AC Neutral to damper mo-
tor1
Relay closure to 230V AC Line
230V AC Line to damper motor2 D21
230V AC Neutral to damper mo-
tor2
Relay closure to 230V AC Line
Text
L
N
PE
V1
V2
PE
EL
EN
PE
C11
C12
PE
C21
C22
D12
D13
D22
D23
