Configurations and settings,
Number of TC-
fans
AC unit
Delta-T FC/AC
Diff. temp. AC-1
Diff. temp. AC-2
Slave mode (PLC)
MODBUS ID-nr:
Factory settings
Factory settings
New?
Language/Språk
Outdoor temp.
Room temp.
SELF TEST
Alarm log
Timer
Menu only shown when function "TC-function" is installed.
1
Menu only shown when function "AC unit" has one or two AC units installed.
2
Menu only shown when logged in as administrator.
3
continued
Parameter
Setting
0-1
1
Not Installed /
1 / 2
0-10°C
2
2-10°C
2
2-5°C
2
Installed/Not in-
stalled
1-247
ENTER=Restore
Enter=Yes
3
English/Swedish
/German
ENTER=START
ENTER=SHOW
ENTER=START
Description
Number of fans that will be set
up for TC-function.
The fan must be connected to
fan group 2. (Y2)
Number of AC units installed
If AC-unit installed:
Shifting from AC-mode to Free
cooling will take place at an
outdoor temperature of "Set-
point cooling"-" Delta-T FC/AC"
Temperature difference be-
tween start and stop of AC unit
1.
Temperature difference be-
tween start and stop of AC unit
2.
Slave mode, the free cooling is
controlled by an external 0-10V
signal
The units ID-number in serial
communication using MODBUS-
protocol
Press ENTER to restore factory
settings.
Press ENTER to save the current
settings as new factory settings
Menu language selection
Measured temperature, from
the outdoor temp sensor
Measured temperature, from
the Room temp sensor
Press ENTER to start self test
Press ENTER to study and reset
the stored alarm log
Press ENTER to activate timer
mode for service personnel
Access
Admin
Admin
Admin
Admin
Continued overleaf
