Self test

Self test
22
TKS 3000A has a built-in test routine for test of connected I/O units.
To start a new test simply step to menu "SELF TEST" (two steps up from main menu) and
push ENTER.
A test according to the table will be executed.
Test phase Time (s)
1 60
2 120
3 60
4 120
5 60
6 10
7 10
8 10
9 10
10 10
11 10
Use "down"-button to go to next phase for a quicker test.
•
Use "up"-button to re-start current phase for longer test phase
•
Use ENTER to immediately quit test.
•
(Phase 2 and 3 can never be forced or manually stopped if internal heater is used.)
Heater active
Exhaust damper opens (if non-motorized dampers are
used this phase ends after 10s).
Fan signal ramps up, 0-100%
TC-function active (if installed).
Fan signal ramps down to min. speed.
AC units active (if installed, if not phase ends after 10s).
0-25s: AC-1 active.
25-35s: AC units shut down.
35-60s: AC-2 active, if installed.
Fan signal = 0%.
Relay output filter alarm active
Relay output fan alarm active
Relay output low temp. alarm active
Relay output high temp. alarm active
Room sensor is tested, result shown after 7s
Outdoor sensor tested, result shown after 7s
Action
