MAINTENANCE
Check torque of the adapter wheel bolt (4) after 20-100 km.
Clean the threaded rod of adjustment bolt (2) every six months and treat with universal grease. [Fig. 9]
Treat sliding surfaces of the lock barrel with thin oil every 6 months. [Fig. 12]
After difficult disassembly of the adjustment bolt (2), check the torque of the adapter wheel bolt (4).
Replacement parts are safety parts!
For the installation of replacement parts into our products, we recommend the use of original AL-
KO parts, or of parts that we have expressly approved for installation. For the clear identification
of replacement parts, our service stations require the replacement part identification number
(ETI).
STORAGE
Cover the threaded bore of the adapter wheel bolt (4) with plugs (8) when the AL-KO PROSAFE is
disassembled.
Following disassembly, store all AL-KO PROSAFE components in the box.
TROUBLESHOOTING
Fault
Lock cannot be closed
Locking rod (3) cannot be
mounted
Adapter wheel bolt (4) can-
not be mounted
Receiver (1) spacing is too
large
1934531_a
Cause
Lock bolt does not fit into groove
Locking rod (3) does not fit
through rim opening
Length of locking rod (3) does
not fit
Inappropriate wheel bolt seat
Other thread size e. g. M14
Incorrect adjustment of adjust-
ment bolt (2)
Minimum compensation height
reached
Solution
Increase spacing of the
adjustment bolt (2) [Fig. 6]
Adjust spacing of locking rod (3) in
the receiver (1) [Fig. 10]
Use the next rim opening
Smaller locking rod D16 can be orde-
red from retailers and AL-KO Web-
shop
Rim is not compatible with AL-KO
PROSAFE
Use the next rim opening
Turn the wheel
Check if taper or ball seat needed
Adapter wheel bolts with additional
thread sizes can be ordered from
retailers and AL-KO Webshop
Not compatible with AL-KO PRO-
SAFE
Decrease spacing of the
adjustment bolt (2) [Fig. 6]
Rim is not compatible with AL-KO
PROSAFE
