UNFOLDING THE STROLLER
Unblock transport hitch of the frame (FIG 5A). Pull the handle of the stroller upwards (FIG 5B) and
spread it until the frame mechanism locks with typical click (FIG 5C).
FRONT AND REAR WHEELS
Mount front wheels in the fasteners from the bottom (FIG 6A) and push rear wheels into the
holes in the rear axle (FIG 6B). Both front and rear wheels should lock into the fasteners with a
characteristic click.
Front wheels are rotatable (FIG 6C). In the front part of front wheels fasteners, levers are located.
Shifting lever upwards will block wheels to a straight drive. Shifting it down will enable wheels to
free turning.
In order to remove front wheels, press button located in the rear part of the wheel fasteners (Fig.
6D). In order to disassemble rear wheels, pull the lock which can be found on the rear axle, and
take out wheels from the fastenings (FIG 6E).
IMPORTANT: Both front and rear wheels are equipped with machine bearings – Penetrant
detergents are forbidden to be used for their cleaning. We recommend only water washing,
mechanical cleaning and drying.
ASSEMBLING AND REMOVING OF UPHOLSTERY
The upholstery in the walking version should be removed when assembling a pram or a car
seat. The seat can be used with the established upholstery, however, we recommend its prior
removal. To install the upholstery, in the first place undo the fixing belts from the tightening pegs
located under the seat (FIG 7A). Then slide the upholstery on the frame from the front (FIG 7B) -
plastic regulations of the footrest should be put precisely in the front part of the upholstery, while
preventing any damage to be done to them. In the upper part of backrest upholstery there are
fasteners which should be set up on the fittings in the upper part of the frame (FIG 7C). Insert the
fastening bolts of the upholstery into the hitch holes on the frame and push them down.
Seat-fixing straps (FIG 7D) should be laid around the tubes of the stand and dragged through the
first mesh of the clamp and reversely through the second one (FIG 7E) then tensioned to fix the
upholstery stably on the seat.
In order to remove upholstery, first undo the straps under the seat by dragging tapes through the
clamp (FIG 7F-7G), then remove upholstery from upper fasteners (FIG 7H). The whole should be
removed from the stand (FIG 7I).
BUMPER
To insert the bumper, you should slide it in the fitting from the top (FIG 8A) until it blocks with a
typical click.
In order to remove bumper press release buttons located on its bottom (FIG 8B) then pull the
bumper out upwards.
BACKREST REGULATION
COCO stroller's backrest has a stepless adjustment. The straps with a blocking mechanism are
used to adjust the position of the backrest (FIG 9A).
To lower the backrest to lying position press button of the mechanism and pull it downwards.
In order to raise the backrest press buttons on both sides of the mechanism and move it, by
holding a wheel at the end of the tape until the backrest will raise to the appropriate level (FIG 9B)
The seat base of COCO stroller is adapted to transport new-born babies (FIG 9C), for this purpose
it requires relevant adjustment of the seat belts (see Fig.13A).
